PC-ISO – High Performance FDM 3D Printing Material
PC-ISO is a high-temperature, high-performance 3D Printing thermoplastic.
- High temperature resistance
- High strength
- Non-toxic
- Non-sensitizing
- Non-irritant
| Mechanical Properties1 | Test Method | English | Metric |
| Tensile Strength (Type 1, 0.125”, 0.2”/min) | ASTM D638 | 8,300 psi | 57 MPa |
| Tensile Modulus (Type 1, 0.125”, 0.2”/min) | ASTM D638 | 289,800 psi | 2,000 MPa |
| Tensile Elongation (Type 1, 0.125”, 0.2”/min) | ASTM D638 | 4% | 4% |
| Flexural Strength (Method 1, 0.05”/min) | ASTM D790 | 13,100 psi | 90 MPa |
| Flexural Modulus (Method 1, 0.05”/min) | ASTM D790 | 310,400 | 2,100 MPa |
| IZOD Impact, notched (Method A, 23°C) | ASTM D256 | 1.6 ft-lb/in | 86 J/m |
| IZOD Impact, un-notched (Method A, 23°C) | ASTM D256 | 1 ft-lb/in | 53 J/m |
| Thermal Properties2 | Test Method | English | Metric |
| Heat Deflection (HDT) @ 66 psi | ASTM D648 | 271°F | 133°C |
| Heat Deflection (HDT) @ 264 psi | ASTM D648 | 260°F | 127°C |
| Glass Transition (Tg) | DMA (SSYS) | 322°F | 161°C |
| Vicat Softening | ISO 306 | 282°F | 139°C |
| Melt Point | – – – – – – – – – | Not Applicable3 | Not Applicable3 |
| Electrical Properties4 | Test Method | Value Range |
| Volume Resistivity | ASTM D257 | 1.5x10e14 – 8.0x10e13 ohms |
| Dielectric Constant | ASTM D150-98 | 3.0 – 2.8 |
| Dissipation Factor | ASTM D150-98 | .0009 – .0005 |
| Dielectric Strength | ASTM D149-09, Method A | 370 – 70 V/mil |
| Other2 | Test Method | Value |
| Specific Gravity | ASTM D792 | 1.2 |
| Flame Classification | UL94 | HB |
1Build orientation is on side long edge.
2Literature value unless otherwise noted.
3Due to amorphous nature, materials does not display a melting point.
4All Electrical Property values were generated from the average of test plaques built with default part density (solid). Test plaques were 4.0 x 4.0 x 0.1 inches (102 x 102 x 2.5 mm) and were built both in the flat and vertical orientation. The range of values is mostly the result of the difference in properties of test plaques built in the flat vs. vertical orientation
Common Applications of PC-ISO
- Medical Products
- Medical Fixtures
- End use tools
- Manufacturing Jigs
Certifications:
- Toxicity (internal)
- Toxicity (external)
- Sensitization
- Irritation
